LABELS
Ve ct or F ® Se ries ▪ O pera to r’s Man ual ▪ MN-468 94 ▪ Rev 1 ▪ 7/2 0
16
10
Line 1 supply terminal
11
Line 2 supply terminal
12
Line 3 supply terminal
13
Neutral
14
Ground terminal
15
Equipotential terminal
—
Press and release the high limit temperature reset
buttons.
LA-36443-L1
LA-36443-L2
LA-36443-L3
LA-36443-N
LA-36443-G
LA-36443-E
LA-39715
VMC-H2, VMC-H3, VMC-H4
VMC-H2H, VMC-H3H, VMC-H4H
VMC-F3, VMC-F4
