INSTALLATION
Ve ct or F ® Se ries ▪ O pera to r’s Man ual ▪ MN-468 94 ▪ Rev 1 ▪ 7/2 0
28
Continued from previous page
Connect the wiring To connect the wiring, do the following.
4. Set the main disconnect switch a to the OFF position.
5. Remove the side panel b.
6. Remove the 4 screws c holding the main disconnect switch to the oven.
Position the terminal block assembly with the main disconnect switch
terminal screws facing up.
Continued on next page
WARNING: Electric shock hazard.
Disconnect the oven from the power supply before
continuing.
VMC-TS-009509
a
VMC-TS-009557
b
VMC-TS-009560
c
