1.0 Survey of models GB
1.1 Model tag
This ALTO high pressure washer has the serial designation C3KA. The model designation appears from
the text on the cabinet, ALTO 52C3KA as an example, and the model tag on the back of the machine (pos.
10).
The tag provides the following details:
1. Manufacture
2. Model designation
3. Production year and week
4. Serial number
5. Rated voltage
6. Electric coupling
7. Mains frequency
8. Power consumption
9. Power absorption
10. Pump pressure
11. Capacity
12. Max. pressure
13. Max. temperature
1.2 Technical data
Model 44C3KA 52C3KA
Pump pressure bar 170 190
Water volume, min/max pressure l/min. 20.0/18.6 21.3/19.6
Max. pressure, inlet water bar 10 10
Min. water supply l/h 1200 1280
Spray lance:
Nozzle diameter h.p./l.p. mm 1.53/3.5 1.53/3.5
Spray angle h.p./l.p. degrees 15/65 15/65
Nozzle type 06 06
Thrust, max. N/kp 49/5.0 54/5.5
Sound pressure level L
pA
measured in accordance with ISO 11202 [DISTANCE 1m] [FULL LOAD]:
78 dB(A).
This machine has been manufactured in accordance with the Low Voltage Directive 73/23/EEC and the
EMC directive 89/336/EEC inclusive of subsequent amendments.
Data at 3 bar inlet pressure and 12°C inlet water.
We reserve the right to make alterations.
