Alto 40C/CA - Survey of ALTO Models; Model Tag Identification; Technical Specifications

3
1.0 Survey of models GB
1.1 Model tag
This ALTO high pressure washer has the serial designation
»40C/40CA« and the type designation »P436/P457«.
The model designation appears from the text on the control panel and
the model tag.
The tag provides the following details:
1. Model
2. Type
3. Serial number
4. Production year
5. Capacity, water volume
6. Max. pressure, opening pressure for by-pass valve
7. Working pressure
8. Max. inlet pressure
9. Max. temperature of inlet water
10. Power absorption of motor
11. Mains frequency
12. Mains voltage
13. Number of phases
14. Power consumption of motor
15. Speed
16. COS ϕ
17. Classification of insulation
18. IP rating
1
3
5
7
9
2
4
6
8
10
12
14
16
18
11
13
15
17
DK-9560 HADSUND
TLF . (+45) 7218 2100
MODEL
TYPE
SERIAL NO
PROD
U
CTION YEAR
CAPACITY
MAX. PRESSURE
WORKING PRESSURE
INLET PRESSURE
INLET TEMPERATURE
MADE IN DENMARK
POWER
FREQUENCY
VOLTAGE
PHASE
POWER CUNSUMPTION
RPM
COS
ϕ
INSULATION CL.
MOISTURE RES. CL.
1.2 Technical data
Model 4040CA 3340C/CA 2040C/CA 1740C/CA
Type P457 P436/P457 P436/P457 P436/P457
Pump pressure bar 200 175 120 110
Water volume, min/max pressure l/min. 16.5/14.8 15.5/14.2 12.7/11.6 12.1/11.1
Pre-priming, max. suction height m
1)
3
1)
3
1)
3
1)
Spray lance:
Nozzle diameter h.p./l.p. mm 1.35/3.5 1.35/3.5 1.35/3.5 1.35/3.5
Spray angle h.p./l.p. degrees 15/65 15/65 15/65 15/65
Nozzle type 05 - yellow 05 - yellow 05 - yellow 05 - yellow
Thrust, max. N/kp 41/4.2 36/3.7 26/2.7 23/2.4
1)
40CA is not pre-priming
2)
GB: 3.0 kW
Sound pressure level L
pA
measured in accordance with ISO 11202 [DISTANCE 1m] [FULL LOAD]:
77 dB(A).
Data at 3 bar inlet pressure and 12°C inlet water.
We reserve the right to make alterations.
