Alto SR400A - Page 21

LEVEL
PART NO ITEM DESCRIPTION SPECIFICATION
PCS
1 MG00349 black screw-T head ψ6 M3*16 12
2 MD00562 ZC-grille-black SR 400A ALTO_V1.0 1
3 MG00511 black screw-flat M4*37_V1.0 2
4 NI02923 treble horn-ABS 280*206.5*17mm black 1
5 MG00530 screw-T head ψ10 M5*30 12
6 NI03153 horn-PP SR 400A. SR 500SA black_V1.0 1
7 ND00231 sponge 10*50*50 1
8 MG00495 black screw-pill M6*13*1.0PH 3
9 NI02924 fixed rack -ABS 84.9114.3*15mm black 1
10 MG00506 black screw-pill M4*35_V1.0 4
11 HG00082 treble driver PA-DE34 P-AUDIO 8ohm 1
12 MG00464 black screw-inner hex-pan head-6.0 M10*30*1.5PH 10
13 MG00338 black screw-T head ψ8 M4*30mm 8
14 NI03152 headle-ABS 85.6*207*7 black _V1.0 2
15 MG00361 black screw-pill M4*20mm 12
16 NI031151 handle cover-ABS SR 400A SR 500SA black_V1.0 2
17 NC00217 K-speaker wooden box SR 400A 12 inch PLYWOOD black paint 1
18 MI01870 ZE-fixed rack-nickel plated SR 400A 5
19 MG00351 black screw-pill M4*16 10
20 HK04468 K-front panel combination SR 400A-ALTO-230V 1
21 ND00367 EV sponge-one side adhesive 2.0t*100*18mmdark black_V1.0 2
22 HK01410 K-speaker -bass 12 inch 1
23 ND00368 EV sponge-one side adhesive 2.0t*378*18mm dark black_V1.0 2
24 ND00374 EV sponge-one side adhesive 2.0t*948*18mm dark black_V1.0 1
25 ND00397 EV sponge-one side adhesive 2.0t*204.5*186.5mm black_V1.0 1
26 MG00353 black screw-semi-circle pan head M6*30 4
27 MH00801 rack hat- black SKC004 1
MECHANICAL PART LIST
MODEL NO
SR400A_ALTO_230V
07-2
