PC00281 SR400A
SR400A_ALTO_230V
REVISED: 2006/5/30
LEVEL PART NO DESCRIPTION SPECIFICATION QTY REFERENCE
├0001---------------------------------
MG00349 screw M3*16 12
├0002---------------------------------
MD00562 iron net SR 400A ALTO_V1.0 1
│└0001-------------------------------
MD00540 iron net SR400A_V1.0 1
│ └0001------------------------------
MD00539 iron net SR400A_V1.5 1
│ └0001-----------------------------
MD00538 iron net 1.2t*607*392mm_V1.1 1
├0003---------------------------------
MG00511 screw M4*37_V1.0 6
├0004---------------------------------
NI02923 high pitch horn 280*206.5*17mm black 1
├0005---------------------------------
MG00350 screw M5*30 12
├0006---------------------------------
NI03153 horn SR400A black_V1.0 1
├0007---------------------------------
ND00231 sponge 15*50*50mm 1
├0008---------------------------------
MG00495 screw M6*13*1.0PH 3
├0009---------------------------------
NI02924 fixed bracket 84.9*114.3*15mm black 1
├0010---------------------------------
HG00082 speaker PA-DE34 Zn P-AUDIO 8Ω 1
├0011---------------------------------
NC00217 box SR-400A 12 inch PLYWOOD_V1.0 1
│├0001-------------------------------
NI03152 handle 85.6*207*7 black_V1.0 2
│├0002-------------------------------
NI03151 handle cover SR400A;SR500SA black_V1.0 2
│├0003-------------------------------
MI01870 fixed bracket SR400A_V1.1 5
││└0001-----------------------------
MI01871 fixed bracket SR400A 3.0t*70*70_V1.1 1
││ ├0001----------------------------
MJ01240 single light board 3.0t*1950*1185mm 54kg 1
││ └0002----------------------------
ME00125 iron pillar M10*9*1PH_V1.1 2
│├0004-------------------------------
MG00464 screw M10*30*1.5PH 10
│├0005-------------------------------
MG00031 screw M4*12 40
│└0006-------------------------------
NC00218 box SR-400A 12 inch PLYWOOD 1
│ ├0001------------------------------
ME00085 nut M4 8
│ ├0002------------------------------
ME00082 nut M5 12
│ ├0003------------------------------
ME00083 nut M6 4
│ ├0004------------------------------
MG00353 screw M6*30 4
│ ├0005------------------------------
MH01704 handle ELVIS φ110*96_V1.0 1
│ │└0001----------------------------
MH00801 bracket φ110*96_V1.1 1
│ ├0006------------------------------
NI02426 foot cushion φ37*15.5mm 4
│ ├0007------------------------------
MG00360 screw M4*25mm 4
│ ├0008------------------------------
MG00338 screw M4*30mm 8
│ ├0009------------------------------
MG00361 screw M4*20mm 12
│ ├0010------------------------------
ND00381 absorb sound sponge 30*300*400mm_V1.0 1
│ └0011------------------------------
ND00382 absorb sound sponge 30*400*750mm_V1.0 1
├0012---------------------------------
MG00351 screw M4*16 10
├0013---------------------------------
ND00367 EV foam 2.0t*100*18mm black_V1.0 2
├0014---------------------------------
ND00368 EV foam 2.0t*378*18mm black_V1.0 2
├0015---------------------------------
ND00374 EV foam 2.0t*948*18mm black_V1.0 1
├0016---------------------------------
ND00397 EV foam φ204.5*φ186.5*2 black_V1.0 1
├0017---------------------------------
HK01410 speaker
12" 150W 4Ω PS 4HA(#2289_LP318.65)
1
│├0001-------------------------------
HG00117 voice coil-RS A0844A_ BK 65-40-335/16-3 1
│├0002-------------------------------
NH00294 cone
U-SONICS NO:CP240/17-SC277A/6-F
1
│├0003-------------------------------
NH00243 cushion C0810A_GR 318/6+2 1
│├0004-------------------------------
ND00310 spider-RS D0839A_CT 65-145/17C3 CNX 1
│├0005-------------------------------
NH00233 cover E0649A_CP 108/C 1
│├0006-------------------------------
MH01649 T type middle pillar H0811A_PN 65/1450.10 D30 1
│├0007-------------------------------
MH01825 washer I0812A_PS 65/1450.8 W J_V1.1 1
│├0008-------------------------------
MH01647 magnet G0450A_D154*73*19mm 1
│├0009-------------------------------
MI01957 holder L0712B_CR 318/J N 1
│├0010-------------------------------
HC00426 terminal M0021B_PT2.1 1
││├0001-----------------------------
HC00496 connect terminal 0.8*13*16.3mm 1
││├0002-----------------------------
HC00495 connect terminal 0.8*13*16.3mm 1
││└0003-----------------------------
NI02583 terminal block 3.5*24.5*3t 1
│├0011-------------------------------
MH01110 rivet M0500A_OU-30 2
│├0012-------------------------------
HA02493 strand TA4X4YKA42W*110mm 2
││└0001-----------------------------
HA02079 strand TA4X4YKA42W*1M
110
│├0013-------------------------------
ND00228 sponge S0720B_NYLON NET D45 1
│└0014-------------------------------
NE16129 lable HK01410_V1.0 1
│ ├0001------------------------------
NI00014 membrane 0.035*1M 1
│ └0002------------------------------
NH00012 bond paper 0.04*1M 1
├0018---------------------------------
HK04468 faceplate SR400A-ALTO-230V 1
│├0001-------------------------------
MA05400 panel SR400A ALTO_V1.1 1
││└0001-----------------------------
MA04000 panel SR-300A 1
││ └0001----------------------------
MA03999 panel SR300A 1.5t*202*26.5*404_V1.1 1
││ ├0001---------------------------
MJ00088 single light board 1.5*2135*1220 30.67kg 1
││ ├0002---------------------------
MI00318 connect terminal PFM-15SA 1
