10
10.24 Disc Error:
When red, indicates that the Test Disc status flag is activated and the timing
disc pattern being sensed did not match the DISC TYPE selected.
10.25 G-Lead:
When red, indicates that the G-lead is grounded.
10.26 Remote:
When red, indicates a remote serial shutdown command is active.
10.27 SD-Lead:
When red, indicates that a shutdown has occurred which was the result of a
grounded G-lead condition.
10.28 SD-Remote:
When red, indicates that a shutdown has occurred as a result of a remote se-
rial shutdown command.
10.29 SD -Overspeed:
When red, indicates that a shutdown has occurred as a result of the engine
reaching the Overspeed setting.
10.30 Wdog1:
When red, indicates that the microprocessor has re-booted since the ignition
has been powered-up.
10.31 Wdog2:
When red, indicates that the microprocessor is currently re-booting. Disregard
the first blink when first connecting.
10.32 ChkSum:
When red, indicates a software checksum failure of the unit’s firmware.
10.33 Low Volt:
When red, indicates that the input DC voltage is at or below the Low Voltage
setting input.
10.34 No Charge:
When red, indicates that the primary storage capacitor has failed to charge
properly within the last ~2 seconds.
10.35 Primary Open:
When red, indicates that an open primary condition has been detected within
the last ~2 seconds.
10.36 Primary Short:
When red, indicates that a shorted primary condition has been detected within
the last ~2 seconds.
10.37 Secondary Open:
When red, indicates that an open secondary condition has been detected
within the last ~2 seconds.
10.38 Cranks Log:
Indicates the total number of crank attempts seen by the CD200D.
10.39 Starts Log:
Indicates the total number of successful starts seen by the CD200D as de-
fined by the Run Speed setting input.
10.40 Cycle Log:
Total number of engine cycles seen by the CD200D.
10.41 Cold Boot Log:
Indicates the number of times the input DC voltage has been cycled to zero.
10.42 Warm Boot Log:
