15
ADDRESS FUNCTION
40026 OUTPUT N EXTRA RETARD DEG
40027 OUTPUT P EXTRA RETARD DEG
40028 OUTPUT R EXTRA RETARD DEG
40029 OUTPUT S EXTRA RETARD DEG
40030 OUTPUT T EXTRA RETARD DEG
40031 OUTPUT U EXTRA RETARD DEG
40032 OUTPUT V EXTRA RETARD DEG
12.8 8 READ/WRITE REGISTERS FOR TIMING SWITCH RET. TABLE
ADDRESS FUNCTION
40033 TIMING SWITCH POS 0 DEG
40034 TIMING SWITCH POS 1 DEG
40035 TIMING SWITCH POS 2 DEG
40036 TIMING SWITCH POS 3 DEG
40037 TIMING SWITCH POS 4 DEG
40038 TIMING SWITCH POS 5 DEG
40039 TIMING SWITCH POS 6 DEG
40040 TIMING SWITCH POS 7 DEG
12.9 21 READ/WRITE REGISTERS FOR LOOP RET. TABLE
ADDRESS FUNCTION
40049 LOOP RET MAP 0mA 0.00V DEG
40050 LOOP RET MAP 1mA 0.25V DEG
40051 LOOP RET MAP 2mA 0.50V DEG
40052 LOOP RET MAP 3mA 0.75V DEG
40053 LOOP RET MAP 4mA 1.00V DEG
40054 LOOP RET MAP 5mA 1.25V DEG
40055 LOOP RET MAP 6mA 1.50V DEG
40056 LOOP RET MAP 7mA 1.75V DEG
40057 LOOP RET MAP 8mA 2.00V DEG
40058 LOOP RET MAP 9mA 2.25V DEG
40059 LOOP RET MAP 10mA 2.50V DEG
40060 LOOP RET MAP 11mA 2.75V DEG
40061 LOOP RET MAP 12mA 3.00V DEG
40062 LOOP RET MAP 13mA 3.25V DEG
40063 LOOP RET MAP 14mA 3.50V DEG
40064 LOOP RET MAP 15mA 3.75V DEG
40065 LOOP RET MAP 16mA 4.00V DEG
40066 LOOP RET MAP 17mA 4.25V DEG
40067 LOOP RET MAP 18mA 4.50V DEG
40068 LOOP RET MAP 19mA 4.75V DEG
40069 LOOP RET MAP 20mA 5.00V DEG
