10.10 Total Retard:
Indicates the total global timing retard at this time. This number is the sum
of the Insertion Retard, Switch Retard, Loop Retard, RPM Retard, and RMT
Global Retard (section 9.21.1).
(Section 12)
12.4 8 READ/WRITE CONFIGURATION BITS SUPPORTS WRITE SINGLE ONLY
READABLE IN MULTIPLES OF 8 BITS STARTING AT 8 BIT BOUNDARIES
ADDRESSES FUNCTION
00001 DISK ON CAM=0 CRANK=1
00002 TEST FOR PROPER DISK YES=1
00003 ENABLE SECONDARY DIAGS YES=1
00004*** reserved
00005*** reserved
00006 SLAVE
00007 reserved
00008 OFF = MAGNETIC Pickup ON = HALL-EFFECT Pickup
NOTE: READ/WRITE Functionality of Energy BIT 0 and BIT 1 in Standard
CD200D - 791090-x is replaced by READ/WRITE functionality of RMT Energy
Selection in CD200D Unit – 791090-xR (Remote Control) (TABLE 12.11)
12.5 4 READ/WRITE REGISTERS MIRROR COIL BITS
ADDRESSES FUNCTION
40001 REG40001=CoilBits 00016-00001
40002 REG40002=CoilBits 00032-00017
40003 REG40003=CoilBits 00048-00033
40004 REG40004=CoilBits 00064-00049
12.6 8 READ/WRITE REGISTERS REGARDING APPLICATION
ADDRESSES FUNCTION
40005 Disk+1 2,3,4,5,6,7,8,9,10,12
40006 Disk Lineup to TDC xx.x DEG
40007 Insertion Ret MIN=2.0 DEG
40008 Purge Delay Cycles 0-255
40009 RPM Over Speed Setpoint
40010 RPM Crank to Run Threshold
40011 Low Supply Voltage Limit
40012 SLAVE ANGLE xx.x DEG
12.7 3 READ/WRITE DEFAULT GLOBAL REGISTERS FOR ENGINE CONTROL
SYSTEM TABLE **
ADDRESSES FUNCTION
40014 Default Global Energy 0,1,2,3
40015 Default Global Timing Retard
40016 Default Individual Retard
