CD200D II 4-17 Addendum
All rights reserved © ALTRONIC, LLC 2017
32
12.11 2 READ/WRITE REMOTE CONTROL REGISTERS FOR
ENGINE CONTROL SYSTEM TABLE (RAM ONLY) **
ADDRESSES FUNCTION
40101 Remote Cont Energy 3,2,1,0 RAM
40102 Remote Cont Global Ret Deg RAM
12.12 12 READ/WRITE REMOTE CONTROL REGISTERS FOR
CYLINDER RET. TABLE (RAM ONLY) **
ADDRESSES FUNCTION
40103 OUTPUT A (01) Indv Ret Deg RAM
40104 OUTPUT B (02) Indv Ret Deg RAM
40105 OUTPUT C (03) Indv Ret Deg RAM
40106 OUTPUT D (04) Indv Ret Deg RAM
40107 OUTPUT E (05) Indv Ret Deg RAM
40108 OUTPUT F (06) Indv Ret Deg RAM
40109 OUTPUT K (07) Indv Ret Deg RAM
40110 OUTPUT L (08) Indv Ret Deg RAM
40111 OUTPUT M (09) Indv Ret Deg RAM
40112 OUTPUT N (10) Indv Ret Deg RAM
40113 OUTPUT P (11) Indv Ret Deg RAM
40114 OUTPUT R (12) Indv Ret Deg RAM
40115 OUTPUT S (13) Indv Ret Deg RAM
40116 OUTPUT T (14) Indv Ret Deg RAM
40117 OUTPUT U (15) Indv Ret Deg RAM
40118 OUTPUT V (16) Indv Ret Deg RAM
12.13 7 READ/WRITE MISC. REGISTERS
ADDRESSES FUNCTION
40122 Crank Counter
40123 Start Counter
40124 Cycle Counter HIGH
40125 Cycle Counter LOW
40126
REG40005 MSB=BAUD LSB=NODEID fixed
9600n81:node1
40127 Cold Boot (powerup) Count
40128 Warm Boot ( reset ) Count
* Registers reordered
** New registers
*** Registers removed
