16
Enter Run Info->
DA=1000 (Example)
1000’ ET=
ET=
TS=
The DA or OA will already be loaded. You should enter a 1000’ ET, a
final ET, and TS. The 1000’ ET is optional and is used for run
completing. You do not have to enter every run with a 1000’ time in
order to use run completing. The TS will only be entered if the unit is in
TS MODE.
To use run completing press the ENTER key when prompted for the
final ET.
If manual entry is desired you must select number 3. After selecting 3
the following is displayed.
ENTER AS
Altitude =1
Temp, Hum, Press =2
Press 1or 2
If 1 is selected you will have to key in the DA or OA value. If 2 is
selected you will have to enter the temperature, humidity, pressure, and
oxygen values. Then the DA or OA will be calculated.
****HINT****
The easiest way to enter a run is by starting from the main menu and
pressing the keys 3, 2, 1, and ENTER. Now all you have to do is type in
your ET’s and the run is stored.
