Altronix AL400UL User Manual

AL400UL - 3 -
XFMR
AL400ULB
3 4
CIT
21
ON
AC AC – BAT +
AC FAIL NC NO C NC C NO LOW BAT
+ DC –
AC DC
DC output
to devices
(power-limited)
Battery and AC
Supervision Circuit
(power-limited)
Battery connection
(non power-limited)
3 4
CIT
21
ON
Switch Position:
24VDC = SW1, 2 OFF
SW3, 4 ON
12VDC = SW1, 2 ON
SW3, 4 OFF
Input
115VAC
Green Ground Lead
Fig. 1
