LED Diagnostics:
Red (DC) Green (AC) Power Supply Status
ON ON Normal operating condition
ON OFF Loss of AC, Stand-by battery supplying power
OFF ON No DC output
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output
Terminal Identification:
Terminal Function/Description
Legend
L, G, N Connect 115 VAC to these terminals:
L to hot, N to neutral, G to ground.
+ DC - 12VDC / 24VDC @ 6 amps continuous non-power limited output.
AC FAIL Used to notify loss of AC power, e.g. connect to audible device or alarm
C, N.C., N.O. panel. Relay normally energized when AC power is present.
Contact rating 1 amp @ 28VDC.
AC or brownout fail is reported within 1 minute of event. To delay reporting of up to
6 hrs., cut “AC delay” jumper and reset power to unit.
BAT FAIL Used to indicate low battery condition, e.g. connect to alarm panel.
N.O., N.C., C Relay normally energized when DC power is present.
Contact rating 1 amp @ 28VDC.
A removed battery is reported within 5 minutes. Battery reconnection is reported
within 1 minute.
Low battery threshold:
12VDC output threshold set @ approximately 10.5VDC,
24VDC output threshold set @ approximately 21VDC.
- BAT + Stand-by battery connections. Maximum charge rate .7 amp.
