9
8. OPERATION
The corresponding remote control buttons are responsible for opening, stopping and closing the roller shutter system:
UBS - control with three remote control buttons ▲, ■, ▼ correspondingly – «open», «stop», «close».
SBS - control with one remote control button in the following sequence: «open - stop - close - stop - stop - ...».
If the safety device has been triggered, the remote control is not possible. To raise/lower the roller curtain in case of emer-
gency, use the buttons on the control unit body - CB keypad (Figure 1) operating in the dead-hand mode.
Before opening/closing the roller shutters, please make sure that no foreign objects or persons are in the area of the roller
shutter. Watch the movement of the curtain. Keep persons away from the rolling curtain until it is completely closed. Do not
touch moving parts of the roller shutter.
The customer and operators of the product must be instructed about danger and risks involved as well as about rules of safe
operation and maintenance.
Do not use the product in case it requires to be serviced.
Signaling of LED D of the control unit
The control unit functions in standby mode
lights green with a short blink
Safety device triggered or no remote control added
~2 seconds of frequent red flashing
The remote control button not used when adding
~2 seconds of frequent red flashing
Troubles and recommendations for their resolution
No control unit indication, motor
doesn't work
No mains voltage, badly
clamped wires in terminals,
fuse destroyed.
Check the mains voltage. Tighten the wires
in the terminals. Check and replace the fuse
if necessary (see how to replace the fuse)
Control unit is indicated, motor axis
does not rotate correctly
Check motor wiring (see Section 4)
The motor is not operated by the re-
mote control (the indicator on the re-
mote control "lights up" and the control
unit indicator ~2 seconds flashes red
frequently)
Safety device has been trig-
gered, or the remote control is
not added to the control unit
memory
Check the operation of the safety devices.
Save the remote control to the control unit
(see Section 7)
The motor is not controlled or does not
react when safety devices are triggered
Wrong selection of safety de-
vice settings or safety device is
faulty
Select the connected safety devices in the
settings (see Section 5). Check the function-
ality of the safety devices, replace them if
necessary
The motor is not controlled by the re-
mote control (the remote control indi-
cator does not light up or is not lit up
brightly)
The remote control battery is
discharged
Check the remote control battery and re-
place it if necessary
The curtain does not stop in end posi-
tions
The end positions are not set
up or are faulty. Incorrect
setting of runtime
Adjust the end positions of the actuator. Re-
adjust the working time of the control unit
(see Section 6)
PROHIBITED! To operate a roller shutter system with defective controls and safety features.
PROHIBITED! To use the product with damaged power cable insulation. If the power cable is damaged, it
must be replaced by the Supplier to avoid danger.
The product is not intended to be used by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience or knowledge, unless they are supervised or instructed how to
use the product by a person responsible for their safety.
Adults must supervise children and not allow children to play with the product.
When carrying out any work (installation, repair, window cleaning, etc.), disconnect the power supply
from the product.
If a fault is detected that cannot be fixed using the information in this manual, please contact customer service.
Contact the supplier for information about service.
