Alva GH309 - Gas Heater Setup; Regulator Connection and Leak Testing

7
4. Set the cylinder support down
onto the cylinder base. (Fig.E)
5. Secure the cylinder support
to the cylinder base using the
2 screws and nuts which you
removed in Step 1. (Fig.F)
6. When connecting the
supplied hose and regulator to
the heater, rst insert the tip of
the hose into hot water for
softening purposes.
7. Remove the 4 Self tapping screws from the unit and then
use these to secure the rear guard in place. (Fig.G)
Fig.G
Fig.E
Fig.F
HOSE TIP
HOSE TIP
HOSE CONNECTOR ON THE HEATER
HOSE CONNECTOR ON REGULATOR
