APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
D-4 990-418
Protocol
1. Single-directional Communication Mode
(When --> is selected at COMM CONTROL in MODE SELECT Screen)
a) Monitor Data
IS-300CA Basic Data strings:
!01001:m,120,1.20,0.50,00.60,20.0,200,2.00,1.50,03.00,40.0,
A B C D E F G H I J K L M
300,2.50,2.00,05.00,50.0,2,0010,5,0100,2222,555555[CR][LF]
N O P Q R S T U V W X
IS-300CA Advanced / EtherNet/IP
TM
Data strings:
!01001:m,120,01.20,0.50,00.60,20.0,200,02.00,1.50,03.00,40.0,
A B C D E F G H I J K L M
300,02.50,2.00,05.00,50.0,2,0010,5,0100,1,0000,1,0000,01,100,
N O P Q R S T U V W X Y Z AA AB
0100,2222,555555,05000,05000,05000,05000,05000,05000,+00.100,
AC AD AE AF AG AH AI AJ AK AL
+01.120[CR][LF]
AM
A Device No. Fixed to 2 digits (01 to 31)
B Schedule No. Fixed to 3 digits (001 to 255)
C Unit of monitor time
m: ms
C: CYC
D Monitor time of WE1
Fixed to 3 digits (000 to 999) (ms)
Fixed to 3 digits (000 to 050) (CYC)
E Monitor current of WE1
Fixed to 4 digits (0.00 to 9.99) (kA)
Fixed to 4 digits (00.0 to 99.9) (kA)
F Monitor voltage of WE1 Fixed to 4 digits (0.00 to 9.99) (V)
G Monitor power of WE1
Fixed to 5 digits (00.00 to 09.99) (kW)
Fixed to 5 digits (000.0 to 999.9) (kW)
H Monitor pulse width of WE1 Fixed to 4 digits (10.0 to 99.9) (%)
I Monitor time of WE2
Fixed to 3 digits (000 to 999) (ms)
Fixed to 3 digits (000 to 050) (CYC)
J Monitor current of WE2
Fixed to 4 digits (0.00 to 9.99) (kA)
Fixed to 4 digits (00.0 to 99.9) (kA)
K Monitor voltage of WE2 Fixed to 4 digits (0.00 to 9.99) (V)
L Monitor power of WE2
Fixed to 5 digits (00.00 to 09.99) (kW)
Fixed to 5 digits (000.0 to 999.9) (kW)
M Monitor pulse width of WE2 Fixed to 4 digits (10.0 to 99.9) (%)
N Monitor time of WE3
Fixed to 3 digits (000 to 999) (ms)
Fixed to 3 digits (000 to 050) (CYC)
To Next Page
