O Monitor current of WE3
Fixed to 4 digits (0.00 to 9.99) (kA)
Fixed to 4 digits (00.0 to 99.9) (kA)
P Monitor voltage of WE3 Fixed to 4 digits (0.00 to 9.99) (V)
Q Monitor power of WE3
Fixed to 5 digits (00.00 to 09.99) (kW)
Fixed to 5 digits (000.0 to 999.9) (kW)
R Monitor pulse width of WE3 Fixed to 4 digits (10.0 to 99.9) (%)
S STEP No. of VALVE1 Fixed to 1 digit (1 to 9)
T STEP COUNT of VALVE1 Fixed to 4 digits (0000 to 9999)
U STEP No. of VALVE2 Fixed to 1 digit (1 to 9)
V STEP COUNT of VALVE2 Fixed to 4 digits (0000 to 9999)
W
COUNTER (WELD/WELD
COUNT of WORK)
Fixed to 4 digits (0000 to 9999)
X
COUNTER (WORK of
TOTAL/GOOD/WORK)
Fixed to 6 digits (000000 to 999999)
The following additional commands are for IS-300CA Advanced / EtherNet/IP
TM
only:
Y STEP No. of VALVE4 Fixed to 1 digit (1 to 9)
Z STEP COUNT of VALVE4 Fixed to 4 digits (0000 to 9999)
AA STEP2 REPEAT Fixed to 2 digits (01 to 99)
AB STEP RATIO Fixed to 3 digits (050 to 200)
AC CAP CHANGE Fixed to 4 digits (0000 to 9999)
AD
COUNTER (WELD/WELD
COUNT of WORK)
Fixed to 4 digits (0000 to 9999)
AE
COUNTER (WORK of
TOTAL/GOOD/WORK)
Fixed to 6 digits (000000 to 999999)
AF FORCE of SQD
Fixed to 5 digits:
00000 to 35000 (N),
00000 to 03569 (kgf), and
00000 to 07868 (lbf)
AG FORCE of SQZ
AH FORCE of WELD1
AI FORCE of COOL1/WELD1
AJ FORCE of COOL2/WELD3
AK FORCE of HOLD
AL WORK DETECT
Fixed to 7 digits (-99.999 to +99.999 (mm))
AM DISPLACEMENT
