APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
D-6 990-418
b) Error Data
IS-300CA Basic Data strings:
!01000:E03,04,12,15,17[CR][LF]
A B C D E F G
A Device No. Fixed to 2 digits (01 to 31)
B Schedule No. Fixed to 3 digits (001 to 255)
C*
1
Error Code 1 Fixed to 3 digits (E01 to E31)
D*
1
Error Code 2 Fixed to 2 digits (01 to 31)
E*
1
Error Code 3 Fixed to 2 digits (01 to 31)
F*
1
Error Code 4 Fixed to 2 digits (01 to 31)
G*
1
Error Code 5 Fixed to 2 digits (01 to 31)
IS-300CA Advanced / EtherNet/IP
TM
Data strings:
!01000:E03,04,12,15,17,19,22,26[CR][LF]
A B C D E F G H I J
A Device No. Fixed to 2 digits (01 to 31)
B Schedule No. Fixed to 3 digits (001 to 255)
C*
1
Error code 1 Fixed to 3 digits (E01 to E39)
D*
1
Error code 2 Fixed to 2 digits (01 to 39)
E*
1
Error code 3 Fixed to 2 digits (01 to 39)
F*
1
Error code 4 Fixed to 2 digits (01 to 39)
G*
1
Error code 5 Fixed to 2 digits (01 to 39)
H*
1
Error code 6 Fixed to 2 digits (01 to 39)
I*
1
Error code 7 Fixed to 2 digits (01 to 39)
J*
1
Error code 8 Fixed to 2 digits (01 to 39)
*1 The maximum number of Error Codes is five for IS-300CA Basic and eight for
Advanced / EtherNet/IP
TM
Models. In the case of only one error code, the error
codes D to G (Basic) and D to J (Advanced / EtherNet/IP
TM
) are omitted.
For Error Codes, see Chapter 5, Maintenance.
*2 Error codes are transmitted when errors are detected.
For the monitored value error and counter error, however, the error is transmitted after
the monitored data is transmitted.
