APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
990-418 D-9
Data Code Table
Screen 01 (SCHEDULE data) Specific data in accordance with Schedule No. (Schedule No.: 001
to 255)
Example of data writing (Advanced / EtherNet/IP
TM
unit):
#01W001S01:0,0,0,m,0000,0000,000,000,000,0000,000,000,000,0000,000,000,000,00000,0000,1
,00.50,00.50,00.50,00.50,00.50,00.50,00.50,00.50,00.50,01,000,01,000,01,000,1000,01,1,001.0,0,
000,99.9,99.9,99.9,010,1[CR][LF]
Item Contents
Character
String
Range
1 Control mode of WELD1 n,
0 to 5;
0: Primary constant-current
effective value control
1: Secondary constant-current
effective value control
2: Secondary constant-power
effective value control
3: Primary constant-current peak
value control
4: Secondary constant-voltage
effective value control
5: Constant-phase control
2 Control mode of WELD2 n,
3 Control mode of WELD3 n,
4 Unit of time *
1
n, m: ms C: CYC
5 SQD / Squeeze delay time nnnn,
0000 to 9999 (ms mode)
0000 to 0999 (CYC mode)
6 SQZ/ Squeeze time nnnn,
0000 to 9999 (ms mode)
0000 to 0999 (CYC mode)
7 UP1 / Upslope 1 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
8 WELD1 / Weld 1 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
9 DOWN1 / Downslope 1 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
10 COOL1 / Cooling 1 time nnnn,
0000 to 9999(ms mode)
0000 to 0999(CYC mode)
11 UP2 / Upslope 2 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
12 WELD2 / Weld 2 time nnn,
000 to 999(ms mode)
000 to 050 (CYC mode)
13 DOWN2 / Downslope 2 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
14 COOL2 / Cooling 2 time nnnn,
0000 to 9999 (ms mode)
0000 to 0999 (CYC mode)
15 UP3 / Upslope 3 time nnn,
000 to 999(ms mode)
000 to 050 (CYC mode)
16 WELD3 / Weld 3 time nnn,
000 to 999(ms mode)
000 to 050 (CYC mode)
17 DOWN3 / Downslope 3 time nnn,
000 to 999(ms mode)
000 to 050 (CYC mode)
18 HOLD / Hold time nnnnn,
00000 to 20000 (ms mode)
00000 to 00999 (CYC mode)
