APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
D-10 990-418
Item Contents
Character
String
Range
19 OFF / Off time nnnn,
0000 to 9990 (ms mode)
0000 to 0099 (CYC mode)
20 CURR RANGE / Current range n, 0: 05 1: 10 2: 20 (kA)
21 UF1 / Initial heat 1 of upslope
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
22 HEAT1 / Heat 1
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
23 DL1 / End heat 1 of downslope
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
24 UF2 / Initial heat 2 of upslope
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
25 HEAT2 / Heat 2
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
26 DL2 / End heat 2 of downslope
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
27 UF3 / Initial heat 3 of upslope
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
28 HEAT3 / Heat 3
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
29 DL3 / End heat 3 of downslope
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
30
PULSATION of WE1 / WE1
repetition
nn, 01 to 19
31 INT1 / Interval 1 nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
32
PULSATION of WE2 / WE2
repetition
nn, 01 to 19
33 INT2 / Interval 2 nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
