APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
990-418 D-11
Item Contents
Character
String
Range
34
PULSATION of WE3 / WE3
repetition
nn, 01 to 19
35 INT3 / Interval 3 nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
36
WELD TRANS FREQ /
Welding transformer frequency
nnnn,
0600 to 3000 (Hz)
Note) The last 2 digits are fixed to 00.
37 GAIN nn, 1 to 9
38 VALVE n, 1 to 2
39 TURN RATIO nnn.n, 001.0 to 199.9
40 WELD ON/OF n, 0: OFF 1: ON
41 VOLT COMP nnn, Fixed to 3 digits (000 to 100) (%)
42 PULSE LIM of WE1 nn.n, Fixed to 4 digits (10.0 to 99.9) (%)
43 PULSE LIM of WE2 nn.n, Fixed to 4 digits (10.0 to 99.9) (%)
44 PULSE LIM of WE3 nn.n Fixed to 4 digits (10.0 to 99.9) (%)
The following is additional data for IS-300CA Advanced / EtherNet/IP
TM
45 MAX CURRENT nnn, 01 to 280 (kA)
46 TRANS# n 1 to 5
*1 The setting of ms/CYC cannot be changed. You can change it via Screen 05 (SYSTEM data).
*3 Screen 02 (MONITOR SET data) Specific data in accordance with Schedule No. (Schedule No.:
001 to 255)
Example of data writing (Basic, Advanced and EtherNet/IP
TM
):
#01W001S02:999,000,99.99,00.00,9.99,0.00,99.99,00.00,100.0,999,000,99.99,00.00,9.99,0.00,99.
99,00.00,100.0,999,000,99.99,00.00,9.99,0.00,99.99,00.00,100.0[CR][LF]
Item Contents
Character
String
Range
1 TIME H of WE1 (upper limit) nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
2 TIME L of WE1 (lower limit) nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
3 CURRENT H of WE1 (upper limit)
n.nn, 0.00 to 9.99 (kA)
nn.n, 00.0 to 99.9 (kA)
4 CURRENT L of WE1 (lower limit)
n.nn, 0.00 to 9.99 (kA)
nn.n, 00.0 to 99.9 (kA)
5 VOLT H of WE1 (upper limit) n.nn, 0.00 to 9.99 (V)
6 VOLT L of WE1 (lower limit) n.nn, 0.00 to 9.99 (V)
7 POWER H of WE1 (upper limit)
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
8 POWER L of WE1 (lower limit)
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
9 PULSE H of WE1 (upper limit) nnn.n, 010 to 100 (%)
10 TIME H of WE2 (upper limit) nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
