APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
D-14 990-418
IS-300CA Advanced / EtherNet/IP
TM
: Screen 03 (STEPPER data) Common data (Valve No.: 001
to 004)
Example of data writing:
#01W001S03:1,0000,0,0000,100,0,0000,100,0,0000,100,0,0000,100,0,0000,100,0,0000,100,0,000
0,100,0,0000,100,0,01,0000[CR][LF]
Item Contents
Character
String
Range
1 START ON STEP # n, 1 to 9
2 COUNT of STEP1 nnnn, 0000 to 9999
3 TIP DRESS of STEP1 n, 0:OFF 1:ON(X)
4 COUNT of STEP2 nnnn, 0000 to 9999
5 RATIO of STEP2 nnn, 050 to 200(%)
6 TIP DRESS of STEP2 n, 0:OFF 1:ON(X)
7 COUNT of STEP3 nnnn, 0000 to 9999
8 RATIO of STEP3 nnn, 050 to 200(%)
9 TIP DRESS of STEP3 n, 0:OFF 1:ON(X)
10 COUNT of STEP4 nnnn, 0000 to 9999
11 RATIO of STEP4 nnn, 050 to 200(%)
12 TIP DRESS of STEP4 n, 0:OFF 1:ON(X)
13 COUNT of STEP5 nnnn, 0000 to 9999
14 RATIO of STEP5 nnn, 050 to 200(%)
15 TIP DRESS of STEP5 n, 0:OFF 1:ON(X)
16 COUNT of STEP6 nnnn, 0000 to 9999
17 RATIO of STEP6 nnn, 050 to 200(%)
18 TIP DRESS of STEP6 n, 0:OFF 1:ON(X)
19 COUNT of STEP7 nnnn, 0000 to 9999
20 RATIO of STEP7 nnn, 050 to 200(%)
21 TIP DRESS of STEP7 n, 0:OFF 1:ON(X)
22 COUNT of STEP8 nnnn, 0000 to 9999
23 RATIO of STEP8 nnn, 050 to 200(%)
24 TIP DRESS of STEP8 n, 0:OFF 1:ON(X)
25 COUNT of STEP9 nnnn, 0000 to 9999
26 RATIO of STEP9 nnn, 050 to 200(%)
27 TIP DRESS of STEP9 n, 0:OFF 1:ON(X)
28 STEP2 REPEAT nn, 01 to 99
29 CAP CHANGE nnnn 0000 to 9999
To Next Page
