APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
990-418 D-15
IS-300CA Basic:
Screen 04 (MONITOR data) (Data reading only). Specific data in accordance
with Schedule No. (Schedule No.: 001 to 255)
Item Contents
Character
String
Range
1 Unit of time n, m: ms C: CYC
2 TIME of WELD1 nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
3 CURRENT of WELD1
n.nn, 0.00 to 9.99 (kA)
nn.n, 00.0 to 99.9 (kA)
4 VOLT of WELD1 n.nn, 0.00 to 9.99 (V)
5 POWER of WELD1
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
6 PULSE of WELD1 nn.n, 00.0 to 99.9 (%)
7 TIME of WELD2 nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
8 CURRENT of WELD2
n.nn, 0.00 to 9.99 (kA)
nn.n, 00.0 to 99.9 (kA)
9 VOLT of WELD2 n.nn, 0.00 to 9.99 (V)
10 POWER of WELD2
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
11 PULSE of WELD2 nn.n, 00.0 to 99.9 (%)
12 TIME of WELD3 nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
13 CURRENT of WELD3
n.nn, 0.00 to 9.99 (kA)
nn.n, 00.0 to 99.9 (kA)
14 VOLT of WELD3 n.nn, 0.00 to 9.99 (V)
15 POWER of WELD3
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
16 PULSE of WELD3 nn.n, 00.0 to 99.9 (%)
17 STEP # of VALVE1 n, 1 to 9
18 STEPPER COUNT of VALVE1 nnnn, 0000 to 9999
19 STEP # of VALVE2 n, 1 to 9
20 STEPPER COUNT of VALVE2 nnnn, 0000 to 9999
21
COUNTER (WELD/WELD
COUNT of WORK)
nnnn, 0000 to 9999
22
COUNTER (WORK of
TOTAL/GOOD/WORK)
nnnnnn 000000 to 999999
