: Screen 04 (MONITOR data) (Data reading only) Specific
data in accordance with Schedule No. (Schedule No.: 001 to 255)
Item Contents
Character
String
Range
1 Unit of time n, m: ms C: CYC
2 TIME of WELD1 nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
3 CURRENT of WELD1
nn.nn, 00.00 to 9.999 (kA)
nnn.n, 000.0 to 999.9 (kA)
4 VOLT of WELD1 n.nn, 0.00 to 9.99 (V)
5 POWER of WELD1
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
6 PULSE of WELD1 nn.n, 00.0 to 99.9 (%)
7 TIME of WELD2 nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
8 CURRENT of WELD2
nn.nn, 00.00 to 9.999 (kA)
nnn.n, 000.0 to 999.9 (kA)
9 VOLT of WELD2 n.nn, 0.00 to 9.99 (V)
10 POWER of WELD2
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
11 PULSE of WELD2 nn.n, 00.0 to 99.9 (%)
12 TIME of WELD3 nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
13 CURRENT of WELD3
nn.nn, 00.00 to 9.999 (kA)
nnn.n, 000.0 to 999.9 (kA)
14 VOLT of WELD3 n.nn, 0.00 to 9.99 (V)
15 POWER of WELD3
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
16 PULSE of WELD3 nn.n, 00.0 to 99.9 (%)
17 STEP # of VALVE1 n, 1 to 9
18 STEPPER COUNT of VALVE1 nnnn, 0000 to 9999
19 STEP # of VALVE2 n, 1 to 9
20 STEPPER COUNT of VALVE2 nnnn, 0000 to 9999
21 STEP # of VALVE3 n, 1 to 9
22 STEPPER COUNT of VALVE3 nnnn, 0000 to 9999
23 STEP # of VALVE4 n, 1 to 9
24 STEPPER COUNT of VALVE4 nnnn, 0000 to 9999
25 STEP2 REPAT nn, 01 to 99
26 STEP RATIO nnn, 050 to 200(%)
27 CAP CHANGE nnnn, 0000 to 9999
28
COUNTER (WELD/WELD
COUNT of WORK)
nnnn, 0000 to 9999
29
COUNTER (WORK of
TOTAL/GOOD/WORK)
nnnnnn 000000 to 999999
30 SQD FORCE nnnnn,
00000 to 35000(N)
00000 to 03569(kgf)
00000 to 07868(lbf)
31 SQZ FORCE nnnnn,
32 WE1 FORCE nnnnn,
33 COOL1/WELD1 FORCE nnnnn,
34 COOL2/WELD3 FORCE nnnnn,
35 HOLD FORCE nnnnn,
