APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
990-418 D-17
Item Contents
Character
String
Range
36 WORK DETECT
+nn.nnn,
-nn.nnn,
-99.999 to +99.999(mm)
37 DISPLACEMENT
+nn.nnn,
-nn.nnn,
Screen 05 (PRE-CHECK data) Specific data in accordance with Schedule No. (Schedule No.: 001
to 255)
Item Contents
Character
String
Range
1 PRECHECK TIME nnn, 000 to 100 (ms)
2 PRECHECK HEAT nn.n, 10.0 to 99.9 (%)
3 PRECHECK RESISTANCE HIGH nn.nn, 00.00 to 99.99 (mΩ)
4 PRECHECK RESISTANCE LOW nn.nn, 00.00 to 99.99 (mΩ)
5*
1
PRECHECK MONITOR nn.nn 00.00 to 99.99 (mΩ)
*1 Items inhibited from setting (When setting data, omit these items.)
IS-300CA Basic:
Screen 06 (SYSTEM data) Common data (Schedule No.: 000)
Item Contents
Character
String
Range
1*
1
POWER SOURCE FREQUENCY nn, 50 or 60 (Hz)
2*
1
Model name nnnnnnnn, IS-300A is same as IS-300CA
3*
1
ROM VERSION Vnn-nnn, V00-00A ~
4 DELAY START SET nn, 01 to 20 (ms)
5 START SIGNAL MODE n,
0: LATCHED 1: PULSED
2: MAINTAINED
3: LATCHED(B) 4: PULSED(B)
5: LATCHED(8) 6: PULSED(8)
6 END SIGNAL TIME nnn, 000, 010 to 200 (ms)
7 END SIGNAL MODE n, 0, 1, 2
8 WELD1 STOP/PARITY CHECK n,
0: WELD1 STOP
1: PARITY CHECK
9 WELD2 STOP/WELD COUNT n,
0: WELD2 STOP
1: WELD COUNT
10 WELD3 STOP/COUNT RESET n,
0: WELD3 STOP
1: COUNT RESET
11 WELD TIME n, 0: ms 1: CYC
12 RE-WELD n, 0: OFF 1: ON
13 SCHEDULE n, 0: EXT 1: INT
14 STEPPER MODE n, 0: OFF 1: FIXED 2: LINER
15 COUNTER n, 0: TOTAL 1: GOOD 2: WORK
16 COMM CONTROL n, 0: OFF 1: --->2: <--->
17 COMM SPEED n, 0: 9.6k 1: 19.2k 2: 38.4k
