APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
D-18 990-418
Item Contents
Character
String
Range
18 COMM MODE n, 0: RS-485 1: RS-232C
19 MONI DISP MODE n, 0: NORMAL 1: LAST
20 PRESET COUNT n, 0: TOTAL/GOOD 1: WELD/WORK
21 TOTAL/GOOD of PRESET COUNT nnnnnn, 000000 to 999999
22
WELD of WELD/WORK,
PRESET COUNT
nnnn, 0000 to 9999
23
WORK of WELD/WORK, PRESET
COUNT
nnnnnn, 000000 to 999999
24 NO CURRENT TIME nn, 01 to 99 (ms)
25 NO CURRENT LEVEL n.nn, 0.00 to 9.99 (kA)
26 NO VOLTAGE LEVEL n.nn, 0.00 to 9.99 (V)
27 MONITOR FIRST TIME nn, 00 to 15 (ms)
28 MONITOR SLOPE MODE n, 0: EXCLUDE 1: INCLUDE
29 WELD STOP OFF TIME of WELD1 nnn, 000 to 999 (ms)
30 WELD STOP OFF TIME of WELD2 nnn, 000 to 999 (ms)
31 WELD STOP OFF TIME of WELD3 nnn, 000 to 999 (ms)
32
OUTPUT MODE of NG SIGNAL
SELECT
n, 0: N.C. 1: N.O.
33
TIME-OVER of NG SIGNAL
SELECT
n, 0: ERROR 1: CAUTION
34
CURR-OVER of NG SIGNAL
SELECT
n, 0: ERROR 1: CAUTION
35
VOLT-OVER of NG SIGNAL
SELECT
n, 0: ERROR 1: CAUTION
36
POWER-OVER of NG SIGNAL
SELECT
n, 0: ERROR 1: CAUTION
37
PULSE-OVER of NG SIGNAL
SELECT
n, 0: ERROR 1: CAUTION
38 NO CURR of NG SIGNAL SELECT n, 0: ERROR 1: CAUTION
39 WRK ERR of NG SIGNAL SELECT n, 0: ERROR 1: CAUTION
40*
1
PROGRAM PROTECT n 0: OFF 1: ON
*1 Items inhibited from setting (When setting data, omit these items.)
“,” is not transmitted, too. In other words, the 4th item (DELAY START SET) will be the first
data.
