Amada IS-300CA - Page 155

APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
990-418 D-19
IS-300CA Advanced / EtherNet/IP
TM
: Screen 06 (SYSTEM data) Common data (Schedule No.: 000)
Example of data writing:
#01W000S06:20,0,200,0,0,0,0,0,0,0,0,0,0,000000,0000,000000,0000,50,0.00,0.00,15,0,000,000,0
00,0,1,1,1,1,1,0,0,0,1,2014,02,27,0,0,0,0,1,2,3,4,1.0[CR][LF]
Item Contents
Character
String
Range
1*
1
POWER SOURCE FREQUENCY nn, 50 or 60 (Hz)
2*
1
Model name nnnnnnnn, IS-300A is same as IS-300CA
3*
1
ROM VERSION Vnn-nnn, V00-00A
4 DELAY START SET nn, 01 to 20 (ms)
5 START SIGNAL MODE n,
0: LATCHED 1: PULSED
2: MAINTAINED
6 END SIGNAL TIME nnn, 000, 010 to 200 (ms)
7 END SIGNAL MODE n, 0, 1, 2
8 WELD1 STOP/PARITY CHECK n,
0:WELD1 STOP
1:PARITY CHECK
9 WELD2 STOP/WELD COUNT n,
0:WELD2 STOP
1:WELD COUNT
10 WELD3 STOP/COUNT RESET n,
0:WELD3 STOP
1:COUNT RESET
11 WELD TIME n, 0: ms 1: CYC
12 RE-WELD n, 0: OFF 1: ON
13 SCHEDULE n, 0:EXT 1:INT
14 STEPPER MODE n, 0:OFF 1:FIXED 2:LINER
15 COUNTER n, 0:TOTAL 1:GOOD 2:WORK
16 COMM CONTROL n, 0:OFF 1:--->2:<--->
17 COMM SPEED n, 0:9.6k 1:19.2k 2:38.4k
18 COMM MODE n, 0:RS-485 1:RS-232C
19 MONI DISP MODE n, 0:NORMAL 1:LAST
20 PRESET COUNT n, 0:TOTAL/GOOD 1:WELD/WORK
21 TOTAL/GOOD of PRESET COUNT nnnnnn, 000000 to 999999
22
WELD of WELD/WORK,
PRESET COUNT
nnnn, 0000 to 9999
23
WORK of WELD/WORK, PRESET
COUNT
nnnnnn, 000000 to 999999
24 NO CURRENT TIME nn, 01 to 99 (ms)
25 NO CURRENT LEVEL n.nn, 0.00 to 9.99 (kA)
26 NO VOLTAGE LEVEL n.nn, 0.00 to 9.99 (V)
27 MONITOR FIRST TIME nn, 00 to 15 (ms)
28 MONITOR SLOPE MODE n, 0: EXCLUDE1: INCLUDE
29 WELD STOP OFF TIME of WELD1 nnn, 000 to 999(ms)
30 WELD STOP OFF TIME of WELD2 nnn, 000 to 999(ms)
31 WELD STOP OFF TIME of WELD3 nnn, 000 to 999(ms)
