APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
D-20 990-418
Item Contents
Character
String
Range
32
OUTPUT MODE of NG SIGNAL
SELECT
n, 0:N.C. 1:N.O.
33
TIME-OVER of NG SIGNAL
SELECT
n, 0:ERROR 1:CAUTION
34
CURR-OVER of NG SIGNAL
SELECT
n, 0:ERROR 1:CAUTION
35
VOLT-OVER of NG SIGNAL
SELECT
n, 0:ERROR 1:CAUTION
36
POWER-OVER of NG SIGNAL
SELECT
n, 0:ERROR 1:CAUTION
37
PULSE-OVER of NG SIGNAL
SELECT
n, 0:ERROR 1:CAUTION
38 NO CURR of NG SIGNAL SELECT n, 0:ERROR 1:CAUTION
39 WRK ERR of NG SIGNAL SELECT n, 0:ERROR 1:CAUTION
40
WORK OVER of NG SIGNAL
SELECT
N, 0:ERROR 1:CAUTION
41
DISPLOVER of NG SIGNAL
SELECT
n, 0:ERROR 1:CAUTION
42*
1
PROGRAM PROTECT n 0:OFF1:ON
43*
1
CONTRAST n, 0 to 9
44*
1
CONTROL# nn, 01 to 31
45 PROGRAMD DATE YEAR nnnn, 2000 to 2099
46 PROGRAMD DATE MONTH nn, 01 to 12
47 PROGRAMD DATE DAY nn, 01 to 31
48 LANGUAGE n, 0:ENGLISH 1:JAPANESE
49 FLOW SWITCH/PRG PROTECT n,
0:FLOW SWITCH
1:PRG PROTECT
50 VALVEMODE n, 0:1 VALVE 1:2 VALVE
51 SCANMODE n, 0:OFF
52 OUTPUT1 n,
0:END
1:COUNTERROR
2:READY
3:STEPEND
4:WELDSIGNAL
5:GOOD
6:COUNTUP
7:OUTI
8:OUTII
53 OUTPUT2 n,
54 OUTPUT3 n,
55 OUTPUT4 n,
56 OUTPUT5 n,
57 DISPL SENSOR STEP n.n 0.5 to 5.0(um)
*1 Items inhibited from setting (When setting data, omit these items.)
“,” is not transmitted, too.
