APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
D-24 990-418
IS-300CA Advanced / EtherNet/IP
TM
: Screen 10 PRESSURE REGULATOR screen Common data
(Schedule No.: 000)
Example of data writing:
#01W000S10:1,0,0,200.0,0.40,00000,00000,00000,000.0,0.00,00000,00000,00000[CR][LF]
Item Contents
Character
String
Range
1 FORCE CONTROL MODE n, 1 to 4
2 FORCE UNIT n, 0:N 1:kgf 2:lbf
3 AIR PRESSURE UNIT n, 0:Mpa 1:bar 2:psi
4 AIR CYLINDER DIAMETER of VALVE1 nnn.n, 000.0 to 500.0(mm)
5 MAX AIR PRESSURE of VALVE1
n.nn,
nn.n,
nnnn,
0.00 to 1.00(Mpa)
00.0 to 10.0(bar)
0000 to 0145(psi)
6
*1
MAXFORCE of VALVE1 nnnnn,
00000 to 99999(N)
00000 to 99999(kgf)
00000 to 99999(lbf)
7
*1
CONSTANT FORCE UP/DW of VALVE1 n, 0:UP 1:DOWN
8 CONSTANT FORCE of VALVE1 nnnnn,
00000 to 35000(N)
00000 to 03569(kgf)
00000 to 07868(lbf)
9
*1
CONSTANT LOW UP/DW of VALVE1 n, 0:UP 1:DOWN
10 CONSTANT LOW of VALVE1 nnnnn,
00000 to 35000(N)
00000 to 03569(kgf)
00000 to 07868(lbf)
11
*1
CONSTANT HIGH UP/DW of VALVE1 n, 0:UP 1:DOWN
12 CONSTANT HIGH of VALVE1 nnnnn,
00000 to 35000(N)
00000 to 03569(kgf)
00000 to 07868(lbf)
13 AIR CYLINDER DIAMETER of VALVE2 nnn.n, 000.0 to 500.0(mm)
14 MAX AIR PRESSURE of VALVE2
n,nn,
nn.n,
nnnn,
0.00 to 1.00(Mpa)
00.0 to 10.0(bar)
0000 to 0145(psi)
15
*1
MAX FORCE of VALVE2 nnnnn,
00000 to 99999(N)
00000 to 99999(kgf)
00000 to 99999(lbf)
16
*1
CONSTANT FORCE UP/DW of VALVE2 n, 0:UP 1:DOWN
17 CONSTANT FORCE of VALVE2 nnnnn,
00000 to 35000(N)
00000 to 03569(kgf)
00000 to 07868(lbf)
18
*1
CONSTANT LOW UP/DW of VALVE2 n, 0:UP 1:DOWN
19 CONSTANT LOW of VALVE2 nnnnn,
00000 to 35000(N)
00000 to 03569(kgf)
00000 to 07868(lbf)
20
*1
CONSTANT HIGH UP/DW of VALVE2 n, 0:UP 1:DOWN
21 CONSTANT HIGH of VALVE2 nnnnn
00000 to 35000(N)
00000 to 03569(kgf)
00000 to 07868(lbf)
*1 Items inhibited from setting (When setting data, omit these items.)
“,” is not transmitted, too.
