IS-300CA ADVANCED INVERTER POWER SUPPLY
990-418 3-1
CHAPTER 3
USING PROGRAMMING FUNCTIONS
Section I. Introduction
This chapter shows Pendant screens used for both Basic, Advanced and EtherNet/IP
TM
models of
the IS-300CA Power Supply. Functions related to the Advanced / EtherNet/IP
TM
models only will
be noted in the text.
FLASH ROM - The Power Supply writes data into FLASH ROM on the control board when a setting
is changed or schedule data is copied. The READY lamp on the front panel and the external READY
signal are turned off during the writing process. It takes about 2 seconds (max) to change a setting
and about 1 minute to copy a schedule into FLASH ROM. During that time, do not turn the power
OFF. When you have finished programming, make sure the READY lamp is turned ON before starting
a welding process.
SHADED CHARACTERS - Items for which a value must be input, or which must be set ON or OFF
will be shaded. Move the cursor to the item and type in the appropriate changes.
