Functional Parts
Part
No:
Description:
20406303 BASE PAN VALVE
CAP020250450RS CAP, 2/25 MFD/450V/DUAL RD
CAP015000500RP CAPACITOR
50A367Q COMPRESSOR, RECHI
RSKP0010 CONTROL BOARD M61
RSKP0005 CONTROL PANEL COVER AND MEMBRANE
11114701 CORD 277 VAC, 20A (M1, M2, M3, M4, M5,
M6, M7, M8, M9, M10, M11)
11114801 CORD 277 VAC, 30A (M12, M13, M14)
0131P00026 FAN MOTOR, INDOOR 265V
0131P00026 FAN MOTOR, OUTDOOR
0161P00030 FAN, CONDENSER
A3410402 FUSE 15A (M1, M2, M3, M4, M5)
A3410403 FUSE 20A (M6, M7, M8, M9, M10, M11)
A3410404 FUSE 25A (M12, M13, M14)
0275P00023 HEATER ASSY (M1, M2, M3, M4, M5)
0275P00024 HEATER ASSY (M6, M7, M8, M9, M10, M11)
0275P00025 HEATER ASSY (M12, M13, M14)
0130M00132 HIGH PRESSURE SWITCH
60343525 OVERLOAD PROTECTOR
0130M00097 RELAY
C8873932 RELAY (POWER VENT) (M3, M4, M11)
0151P00001 REVERSING VALVE ASSY-265V
0130P00022 REVERSING VALVE COIL
0130P00074 THERMISTOR
0130P00093 THERMISTOR
0130P00077 THERMISTOR (M3, M5, M8, M10, M14)
0130P00075 THERMISTOR-DISCHARGE
0130P00086 THERMISTOR-INDOOR COIL
0130P00098 THERMISTOR-OUTDOOR AMBIENT (M3, M5,
M8, M10, M14)
11172101 TRANSFORMER (M3, M4, M11)
20512501 TRANSFORMER (HYDRONIC)
0150P00004 WHEEL, BLOWER
Expanded Model Nomenclature
M1 - PTH154G25AXXXAA
M2 - PTH154G25CXXXAA
M3 - PTH154G25DRXXAA
M4 - PTH154G25DXXXAA
M5 - PTH154G25RXXXAA
M6 - PTH154G35AXXXAA
M7 - PTH154G35CXXXAA
M8 - PTH154G35QRXXAA
M9 - PTH154G35QXXXAA
M10 - PTH154G35RXXXAA
M11 - PTH154G35VXXXAA
M12 - PTH154G50AXXXAA
M13 - PTH154G50CXXXAA
M14 - PTH154G50RXXXAA
3
RP-738B
www.goodmanmfg.com
www.amana-hac.com
