Amana 153G User Manual

Front Assy
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
FRONT-DICHARGE LOUVERS 0161P0003311
CONTROL BOARD M61 RSKP001021
TRANSFORMER (HYDRONIC) 2051250131
CLIP (QTY 2)0163P0002541
CONTROL PANEL COVER 0121P00001P51
SCREEN, DISCHARGE 0121P0007361
DOOR ASSY -AMANA- 0261P0000371
FRONT ASSY 0261P0001181
BAYONET FUSE HOLDER (M1, M2, M3, M4, M5)C647600191
BAYONET FUSE HOLDER (M6, M7, M8, M9, M10,
M11)
C647600291
BAYONET FUSE HOLDER (M12, M13, M14)C647600391
CAP, 2/25 MFD/450V/DUAL RD CAP020250450RS101
TRANSFORMER (M3, M4, M11)11172101111
RELAY 0130M00097121
RELAY (POWER VENT) (M3, M4, M11)C8873932121
DIGITENNA (M3, M5, M8, M10, M14)1261401261
PADDLE SWITCH (M3, M4, M11)B1337701291
FILTER, RACK (QTY 2)0161P00035NS
FUSE 15A (M1, M2, M3, M4, M5)A3410402NS
FUSE 20A (M6, M7, M8, M9, M10, M11)A3410403NS
FUSE 25A (M12, M13, M14)A3410404NS
TERMINAL BOARD (M3, M4, M11)B1160701NS
Expanded Model Nomenclature
M1 - PTH154G25AXXXAA
M2 - PTH154G25CXXXAA
M3 - PTH154G25DRXXAA
M4 - PTH154G25DXXXAA
M5 - PTH154G25RXXXAA
M6 - PTH154G35AXXXAA
M7 - PTH154G35CXXXAA
M8 - PTH154G35QRXXAA
M9 - PTH154G35QXXXAA
M10 - PTH154G35RXXXAA
M11 - PTH154G35VXXXAA
M12 - PTH154G50AXXXAA
M13 - PTH154G50CXXXAA
M14 - PTH154G50RXXXAA
