Amana 153G User Manual

Front Assy
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
FRONT-DICHARGE LOUVERS 0161P0003311
CONTROL BOARD M61 RSKP0010
21
TRANSFORMER (HYDRONIC) 20512501
31
CLIP (QTY 2)0163P00025
41
CONTROL PANEL COVER 0121P00001P
51
SCREEN, DISCHARGE 0121P00073
61
DOOR ASSY -AMANA- 0261P00003
71
FRONT ASSY 0261P00011
81
CAP, 5/30 MFD/450V/DUAL RD CAP050300450RS
101
TRANSFORMER (M4, M8, M12, M15, M17, M19)B1378501
111
RELAY 0130M00096
121
RELAY (HYDRONIC) (M16)C8873917121
RELAY (POWER VENT) (M4, M8, M12, M15, M17,
M19)
C8873932
121
DIGITENNA (M3, M6, M9, M11, M17, M18)DT01A
261
PADDLE SWITCH (M4, M8, M12, M15, M17, M19)B1337701291
FILTER, RACK (QTY 2)0161P00035
NS
TERMINAL BOARD (M4, M8, M12, M15, M17, M19)B1160701
NS
Expanded Model Nomenclature
M1 - PTH153G25AXXXAA
M2 - PTH153G25CXXXAA
M3 - PTH153G25RXXXAA
M4 - PTH153G25VXXXAA
M5 - PTH153G35AXXXAA
M6 - PTH153G35CRXXAA
M7 - PTH153G35CXXXAA
M8 - PTH153G35DXXXAA
M9 - PTH153G35QRXXAA
M10 - PTH153G35QXXXAA
M11 - PTH153G35RXXXAA
M12 - PTH153G35VXXXAA
M13 - PTH153G50AXXXAA
M14 - PTH153G50CXXXAA
M15 - PTH153G50DXXXAA
M16 - PTH153G50PXXXAA
M17 - PTH153G50RVXXAA
M18 - PTH153G50RXXXAA
M19 - PTH153G50VXXXAA
5
RP-737A
www.goodmanmfg.com
www.amana-hac.com
