Amana 153G User Manual

Chassis Control Panel
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
SHROUD, CONDENSER 0161P0002611
FAN MOTOR OUTDOOR 0131P00025
21
PANEL-PARTITION (M9, M10)0121P00093
31
PANEL-PARTITION PNT (M1, M2, M3, M4, M5, M6,
M7, M8, M11, M12, M13, M14, M15, M16, M17,
M18, M19)
0121P00108DG
31
FAN, CONDENSER 0161P00030
41
CABLE 0163P00019
51
BRACKET, VENT DOOR (M4, M8, M12, M15, M17,
M19)
0121P0007961
BRACKET, VENT DOOR-C (M1, M2, M3, M5, M6,
M7, M11, M13, M14, M16, M18)
0121P00072DG
61
BRKT, POWER VENT (M4, M8, M12, M15, M17,
M19)
0121P00080
61
POWER VENT MOTOR BRACKET (M4, M8, M12,
M15, M17, M19)
11166101
61
VENT DOOR (M2, M6, M7, M14)11046105PDG
71
PARTITION PANEL BRACKET (QTY 2)1119170381
LEVER ARM (M1, M2, M3, M5, M6, M7, M11, M13,
M14, M16, M18)
11046302
91
POWER DOOR ASSY (M8, M15)0270P00997
191
EXTENSION SPRING (M4, M8, M12, M15, M17,
M19)
11166401NS
PANEL-AUXILLIARY (M9, M10)0121P00091
NS
POWER VENT COVER BRACKET (M4, M8, M12,
M15, M17, M19)
11166201
NS
POWER VENT MOTOR (M4, M8, M12, M15, M17,
M19)
11172801
NS
THERMISTOR-OUTDOOR AMBIENT (M3, M6, M9,
M11, M17, M18)
0130P00098
NS
Expanded Model Nomenclature
M1 - PTH153G25AXXXAA
M2 - PTH153G25CXXXAA
M3 - PTH153G25RXXXAA
M4 - PTH153G25VXXXAA
M5 - PTH153G35AXXXAA
M6 - PTH153G35CRXXAA
M7 - PTH153G35CXXXAA
M8 - PTH153G35DXXXAA
M9 - PTH153G35QRXXAA
M10 - PTH153G35QXXXAA
M11 - PTH153G35RXXXAA
M12 - PTH153G35VXXXAA
M13 - PTH153G50AXXXAA
M14 - PTH153G50CXXXAA
M15 - PTH153G50DXXXAA
M16 - PTH153G50PXXXAA
M17 - PTH153G50RVXXAA
M18 - PTH153G50RXXXAA
M19 - PTH153G50VXXXAA
7
RP-737A
www.goodmanmfg.com
www.amana-hac.com
