Partition Assy
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
BASEPAN, PNT 0121P00056DG11
PLASTIC-DRAIN PAN 0161P00044
21
CAPACITOR STRAP C6300502
51
TOP - PARTITION PANEL (M2, M6, M7, M14)0121P00063DG
71
CAPACITOR CAP020000440RP
81
BRACE, TIE PNT (QTY 2)0121P00071DG
101
CORD, 250VAC, 15A (LCD) (M1, M2, M3, M4)0130P00069
121
CORD, 250VAC, 20A (LCD) (M5, M6, M7, M8, M9,
M10, M11, M12)
0130P00058
121
CORD, 250VAC, 30A (LCD) (M13, M14, M15, M16,
M17, M18, M19)
0130P00062
121
CONTROL PANEL COVER AND MEMBRANE RSKP0005
131
PLASTIC-HOOD 0161P00016141
ACCESS COVER 20410801
151
CUTOFF-SCROLL DG 0121P00061DG
161
COVER, MOTOR PNT 0121P00070DG
171
MID PARTITION PANEL 20403301
NS
SEAL-L SIDE PTC 20416201
NS
SEAL-R SIDE PTC 20416101
NS
Expanded Model Nomenclature
M1 - PTH153G25AXXXAA
M2 - PTH153G25CXXXAA
M3 - PTH153G25RXXXAA
M4 - PTH153G25VXXXAA
M5 - PTH153G35AXXXAA
M6 - PTH153G35CRXXAA
M7 - PTH153G35CXXXAA
M8 - PTH153G35DXXXAA
M9 - PTH153G35QRXXAA
M10 - PTH153G35QXXXAA
M11 - PTH153G35RXXXAA
M12 - PTH153G35VXXXAA
M13 - PTH153G50AXXXAA
M14 - PTH153G50CXXXAA
M15 - PTH153G50DXXXAA
M16 - PTH153G50PXXXAA
M17 - PTH153G50RVXXAA
M18 - PTH153G50RXXXAA
M19 - PTH153G50VXXXAA
9
RP-737A
www.goodmanmfg.com
www.amana-hac.com
