Main Assembly (continued)
19
Item Ref. No. Description Qty
1 MP498500 HANDLE, ASM. 1
2 21088A FRAME, MAIN 1
3 80294A SCREW, SH, 5/16” X 1-5/8” 4
4 61725A AXLE 1
5 61740A ARM, LINK, LEFT 1
6 61741A ARM, LINK, RIGHT 1
7 80295A WASHER, BOWED, .516” ID 2
8 980648 WASHER, 17/32” ID 2
9 980673 WASHER, FLAT, 1/2” 2
10 39857A WHEEL, 5” 2
11 80292A SCREW, 1/4” X 1.00” 2
12 11006A SHROUD, w/ BUMPER, ASM. 1
13 53650A MOTOR/GEARBOX, 1.5HP 1
14 53833A PIN, SPLIT, 1/2” 2
15 56109699 CAM, w/ GRIP, ASM. 1
16 920342 NUT, LOCK, 3/8” 1
Item Ref. No. Description Qty
17
MP481100 DRIVER, PAD
1
18 MP499200 DECAL, HANDLE, 225FP 1
19 980349 WASHER, WEAR 1
20 MP484900 TANK, WATER, 2-1/2 GAL, ASM. 1
21 56383098 SKIRT, TALL 1
22 NB021600 CLAMP, 3/8” 1
23 NB064900 SCREW, #10 X 1/2” 1
24 40722A CORD, POWER, 12/3, 40FT 1
25 MP486401 PLATE, MOUNTING 2
26 NB019100 BOLT, HEX, 1/4” X 3/4” 4
27 NB6110 WASHER, LOCK, 1/4” 4
28 NB3350 WASHER, FLAT, 1/4” 4
29 MP473900 TUBING, 1/4” ID 24”
30 MP498300 DECAL, APEC, 3” 1
31 MP487700 CAP, 6”, TANK 1
32 70825A LABEL, HDTR, 2” X 5” 2
To Next Page
