SPECIFICATIONS
PAGE 7MICRO20/MACRO80P INSTALLATION & OPERATION MANUAL
MACRO80P
WOOFER Diameter 160mm
POWER RMS 40W
Program 80W
Peak 160W
SENSITIVITY (1W/1m) 90dB
FREQUENCY RESPOSNSE (±3dB) 39Hz-190Hz
SUB POWER OUTPUT 4 ohms, 1% THD, RMS 70W
SATELLITE POWER OUTPUT 8 ohms, 1% THD, RMS 15W
4 ohms, 1% THD, RMS 25W
2 ohms, 1% THD, RMS Not Recommended
SUB BANDPASS 40Hz-175Hz
SATELLITE BANDPASS 80Hz-30kHz
INPUT SENSITIVITY 85mV
CURRENT DRAW 1.2A max
FUSE RATING 250V, 2A, SB
DIMENSIONS (H X W X D) 405mm x 270mm x 345mm
SHIPPING DIMENSIONS (H X W X D) 500mm x 410mm x 360mm
SHIPPING WEIGHT 15.7kg
WMVC
EQ CONTROLS Bass 100Hz ±10dB
Treble 10kHz, ±10dB
MAX CABLING DISTANCE 50m
DIMENSIONS (H X W X D) 115mm x 75mm x 44mm
SHIPPING DIMENSIONS (H X W X D) 80mm x 130mm x 85mm
SHIPPING WEIGHT 0.2kg
