AmazonBasics DF500 User Manual

6
Electronic Flash Diagram
1. Wide angle diffuser
2. Flash bounce card
3. Flash head
4. Wireless sensor
5. External power
source socket port
6. PC synchronous
socket port
7. Lock ring
8. Hot shoe foot
3
4
5
6
7
8
2
9. MODE indicator (M, S1, S2)
10. Battery cover
11. Power indicator
12. TEST button
13. Flash MODE button
14. Output level indicator
15. Flash power level – button
16. Flash power level + button
17. Power switch
18. Hot shoe stand
9
10
11
12
13
14
15
16
17
18
1

AmazonBasics DF500 Specifications

General

Brand	AmazonBasics
Model	DF500
Category	Camera Flash
Language	English
