Operating Instructions
1. Turn the Electronic Flash ON/OFF
Note: If the Electronic Flash will not be used for
an extended time, slide the Power switch to
OFF and remove the four batteries.
–
Slide the Power switch to ON. All lights will
flash once. The Electronic Flash will start
charging when the POWER light is green.
– To test flash, press the TEST button.
–
To turn off the Electronic Flash, slide the
Power switch to OFF.
2. Light intensity output
The Electronic Flash has eight light intensities. The eight intensities are
shown on the eight vertical bars on the display panel. The light intensity level
being used at any time is indicated on the corresponding lighted vertical bar.
The levels are adjusted by cycling through the
+ button and – button. Light
intensity levels include: 1/128, 1/64, 1/32, 1/16, 1/8, 1/4, 1/2, and 1/1 (full
power output).
3. M MODE
On M MODE (manual mode), flash brightness is selected manually. Select the
light intensity and adjust the camera by pressing the shutter. The Electronic
Flash will flash under the camera synchronous signal.
4. S1 MODE
S1 MODE (slave mode) can only be used when the camera or master flash
is on M MODE. On S1 MODE the Electronic Flash will trigger the flash
synchronously with the first flash of the camera or master flash. This mode
cannot be used if the camera is on TTL MODE.
')
