Apollo3 Blue Plus EVB Quick Start Guide
Ultra-Low Power Apollo MCU Family
QS_A3P_1p1 Page 13 2020 Ambiq Micro, Inc.
All rights reserved.
cut to make U8 (VDD_PS_LDO generator) output 1.9V instead of 1.8V in the low-voltage configuration.
This will enable current consumption measuring using equipment with a sensing resistor, such as a digital
multimeter.
Figure 9. Solder Bridge SB1
