Ambrell 3542 - Auxiliary Output Modes

Technical Information
69
A
MBRELL
801
-
9526
-
00.doc
Precision Induction Heating
6
6
.
.
3
3
A
A
u
u
x
x
i
i
l
l
i
i
a
a
r
r
y
y
O
O
u
u
t
t
p
p
u
u
t
t
M
M
o
o
d
d
e
e
s
s
a
a
n
n
d
d
S
S
c
c
a
a
l
l
i
i
n
n
g
g
E
E
x
x
a
a
m
m
p
p
l
l
e
e
s
s
Note: Full scale power is model-dependant. For example, model 8310 has a max power
of 10kW. See “Equipment Input/Output” for complete listing of specifications for all
models.
0—20mA Scale in “Power” mode: Model 8310 (10,000 Watts max rated)
Where (Power in Watts)=(Aux_out_mA)*(max power in watts)/20
mA output Watts
1 500
5 2,500
10 5,000
20 10,000
4—20mA Scale in “Power” mode: Model 8310
Where (Power in Watts)=(Aux_out_mA-4)*(max power in watts)/16
mA output Watts
5.6 1,000
8 2,500
12 5,000
20 10,000
Note: Full scale Amps depends on the tap number in use. Refer to the Workhead
Operations Manual for complete specifications. See also “Heat Station” and “Tap
Adjustment”.
0—20mA Scale in “Amps” mode
Where Max Amps = Tap*25 (i.e., tap 22 would result in a full scale value of 22*25=550
amps.)
(Current in Amps)=(Aux_Out_mA)*(Max_Amps)/20
mA output Amps
0 0
2 55
10 275
20 550
