EN
16
Storage and transportation
Temperature 10 ~ 40°C (50 ~ 104°F) 10 ~ 40°C (50 ~ 104°F)
Relative humidity 30 ~ 85% 30 ~ 85%
Atmospheric pressure 80 ~ 109 kPa 80 ~ 109 kPa
Sterilisation
Method of sterilisation EtO EtO
3 Please be aware that the bending angle can be affected if the insertion cord is not kept straight
4 There is no guarantee that accessories selected solely using this minimum instrument channel width will be compatible in combination.
5.2. aView Specifications
Display
Max. resolution 800
*
480
Orientation Landscape
Display type 8.5” colour TFT LCD
Brightness control Yes, (“+” / ”-“)
Contrast control Yes, (“+” / ”-“)
Start up time About 1 second
Memory
Storage capacity 8GB
Electrical power
Power requirement 18V 1,67A DC input
Battery type 11,1V 3760mAh
Operating environment
Temperature 10 ~ 40° C (50 ~ 104° F)
Relative humidity 30 ~ 85%
IP Protection Classification System The aView is classified IP30.
Atmospheric pressure 80-109 kPa
Altitude ≤ 2000m
Dimensions
Width 241mm (9.49")
Height 175mm (6.89")
Thickness 33,5mm (1,32")
Weight 1500g (331lbs)
Connections
USB connection Type A
Storage and transportation
Temperature 10 ~ 40°C (50 ~ 104°F)
Relative humidity 30 ~ 85%
Atmospheric pressure 80-109 kPa
Mounting interface
Mounting interface standard VESA MIS-D, 75 C, VESA FDMI compliant display, Part D, with centre located mounting interface
