5.2. Specifications
Infant Pediatric Adult
Resuscitator volume approx. 220 ml approx. 670 ml approx. 1510 ml
Delivered volume one hand* 150 ml 450 ml 600 ml
Delivered volume two hands* - - 1000 ml
Dimensions
(length x diameter) w/o
reservoir and accessory
approx.
190 x 71mm
approx.
223 x 99mm
approx.
284 x 127mm
Weight w/o reservoir
and accessory
approx. 70 g approx. 145 g approx. 220 g
Pressure-limiting valve**
4.0 kPa
(40cm H
2
O)
4.0 kPa
(40cm H
2
O)
4.0 kPa
(40cm H
2
O)
Dead space
≤ 5 ml + 10 % of the
delivered volume
≤ 5 ml + 10 % of the
delivered volume
≤ 5 ml + 10 % of the
delivered volume
Inspiratory resistance***
max 0.1 kPa
(1.0cm H
2
O)
at 5l/min
max 0.5 kPa
(5.0cm H
2
O)
at 50l/min
max 0.5 kPa
(5.0cm H
2
O)
at 50l/min
Expiratory resistance***
max 0.2 kPa
(2.0cm H
2
O)
at 5l/min
max 0.27 kPa
(2.7cm H
2
O)
at 50l/min
max 0.27 kPa
(2.7cm H
2
O)
at 50l/min
Reservoir volume
approx. 300 ml (bag)
approx. 100 ml (tube)
approx. 2600 ml (bag) approx. 2600 ml (bag)
Patient connector
Outside 22mm male (ISO 5356-1)
Inside 15mm female (ISO 5356-1)
Expiration connector
(for PEEP valve attachment)
30mm male (ISO 5356-1)
Manometer Port connector Ø 4.2 +/- 0.1mm
Demand Valve connector - Inside 32 mm female (EN ISO 10651-4)
Infant Pediatric Adult
Forward and
backward leakage
Not measurable
M-Port Connector compatible with EN ISO 80369-7
O
2
inlet connector According to EN 13544-2
Operation temperature limits -18 °C to +50 °C (-0.4 °F to +122 °F), tested according to EN ISO 10651-4
Storage temperature limits -40 °C to +60 °C (-40 °F to +140 °F), tested according to EN ISO 10651-4
Recommended long term storage in closed packaging at room temperature, away from sunlight.
* Tested according to EN ISO 10651-4.
** Higher delivery pressure can be obtained by overriding the pressure-limiting valve.
*** At general test conditions according to EN ISO 10651-4.
5.3. MRI Safety Information
The Ambu SPUR II Resuscitator
1
, and Ambu SPUR II Resuscitator with attached Ambu
Disposable PEEP 20 Valve
2
, and Ambu SPUR II Resuscitator with attached Ambu Disposable
PEEP 20 Valve and Ambu Disposable Pressure Manometer
2
are MR Conditional, and
therefore may be safely used in the MR environment (not inside the MR bore) under the
following conditions.
Static magnetic field of 7 Tesla and less, with
• Maximum spatial field gradient of
– 10,000 G/cm (100 T/m)
1
– 16,000 G/cm (160 T/m)
2
• Maximum force product of
– 450,000,000 G2/cm (450 T
2
/m)
1
– 721,000,000 G2/cm (721 T
2
/m)
2
Use inside the MR bore may influence MR image quality.
RF-induced heating and MR image artifacts have not been tested. Any metallic parts are
fully encapsulated and do not have any contact with the human body.
