Specifications
Model Number AD 400E
Power Supply 120V / 60Hz / 1 Phase
Power Consumption 446W / 3.92A
Humidity Removal Capacity 43.5 pints / Day
Refrigerant R-22 / 11.8 oz.
Weight 46.3 lbs.
Dimensions 16"W x 28"D x 10"H
2
Always unplug the unit from the wall outlet before beginning cleaning.
The unit is equipped with a washable filter. Follow the instructions below to remove and clean it.
Cleaning the Filter
• Wash filter in warm water.
• Shake out excess water, lay flat, away from heat, until thoroughly dry.
• Do not use hot water, solvents, detergent, or abrasive, material to clean filter.
This may damage the element.
• Clean filter every two weeks.
To clean the outside of unit, use moist cloth. Avoid detergent and abrasive wipes.
fig.1
fig.1
fig.3
fig.2
How to Remove Filter
Take out the air filter by pressing the top of the air inlet grill (as shown in fig.1).
Pull out the grill (fig.2) and extract the filter (fig.3).
Maintenance
