Figure 5–2 AMD CrossFire™ Bridge Interconnect Protection Tag
Figure 5–3 AMD CrossFire™ Installation
1 AMD CrossFire graphics cards
2 Interconnect
9. Fasten the graphics cards securely to the back panel.
18 AMD CrossFire™ Technology
AMD Radeon™ HD 7900 Series © 2013 Advanced Micro Devices, Inc.
