Heritage & Titan Gas Ranges
Use & Care Manual
OVERALL DIMENSIONS TITAN GAS RANGES
UNIT "A" IN. "B" IN. "C" IN.
24" 23.875 18 11
30" 29.875 20-1/2 11
36" 35.875 24 11
48" 47.875 20-1/2 11
60" 59.875 20-1/2 11
