Owner’s Manual
ARSM, ARSB, ARCM, AROB, AVB
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com
9
ARSB
ITEM NO. PART NO. DESCRIPTION
2
A14015 Burner, Infrared ARSB 10477 Old Style 12-3/4" x 7"
3
A80011 Valve, Pressure Regulator 3/4 10481 LP Gas Set 10.0
A80110 Valve, Pressure Regulator 3/4 10480 Nat Gas Set 5.
4 A43007 Bearing, Ball Sm 1/4" ID x 1" OD 10491 High Heat
5
A31021 Rack, ARSB-36" 2901/2" x 13" 10505 Old Style
7 A32150 Bracket, Door Handle Heavy Duty 18164-Chrome Plated AR Range
8 A53071 Tube, Handle ARSM-36" Heavy Duty .049W 1-1/4" x CTL 180 Grit
9 A32016 Knob, Ball 1-3/4 3/8 Insert 10490 New Style
10 A43017 Bearing, Ball 3/4" ID x 1-5/8" OD 10507 High Heat
12 A38000 Name Plate, American Range 8" 10499 Quality Commercial Chrome
13 A44003 Nut, Speed #6 Push Black 10601
14
A99543 Crumb Tray, ARSB-36" 10285
15 A32001 Knob, On/Off Glossy Black Flat Down
16 A80109 Valve, Gas Manual On/Off UL 10419 AR, ARKB, ARRB, AECB
17 A29302 Valve, Pilot Straight Adj. 10436 3/16CC - 1/8 MNPT
18 A15040 Manifold, ARSB-36" Dual Burners 10286
20
A11108 Pilot, Nat gas .026 3/16" 6CH24-2 "T" Style ARSB
A11109 Orice, Bell 0.014L VL LP Gas 11107 AF-Series
A11118 Orice, Bell 0.018 AR/AF Nat Gas 11001
21 A28002 Connector, Male 3/8CC x 1/8 MPT 10014 Compression Fitting
