American Range ARSM - Page 15

Owner’s Manual
ARSM, ARSB, ARCM, AROB, AVB
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com
11
ARCM
ITEM NO. PART NO. DESCRIPTION
2
A29014 Hood, Orice #36 1/2" Brass 11036
A29004 Hood, Orice #50 1/2" Brass 11050
A29002 Hood, Orice #46 1/2" Brass 11046
A29005 Hood, Orice #55 1/2" Brass 11055
4
A31011 Rack, ARCM 24" 20-1/4" x 15-1/2" Chrome Plated
A31012 Rack, ARCM 36" 32-1/4" x 15-1/2" Chrome Plated
A31013 Rack, ARCM 48" 44-1/4" x 15-1/2" Chrome Plated
A31014 Rack, ARCM 60" 56-1/4" x 15-1/2" Chrome Plated
5
A80110 Valve, Regulator 3/4 10480 LP Gas Set 5.
A80011 Valve, Regulator 3/4 10481 LP Gas Set 10.0
6
A28002 Connector, Male 3/8" CC x 1/8 MPT 10014 Compression Fitting
8
A11112 Pilot, Nat Gas .018 ARSM/ARCM 10489 "L" Style
9
A11118 Orice, Bell .018 AR/AF Nat Gas 11001
A11110 Orice, Bell 0.010 LPG Gas 11002
10
A28021 Sleeve, Ball 3/16" Tube Barrel Oversize
11
A28020 Nut, Reducer 1/4"-3/16CC 10428
12
A53025 Tubing, Aluminum 3/8" (sold per foot)
13
A32001 Knob, Gas On/Off Glossy Black Flat Down
14
A38000 Name Plate, American Range 8" 10499 Quality Commercial Chrome
17
A44003 Nut, Speed #6 Push Black 10601
18
A15038 Manifold, ARCM/ARSM 24"/36" New Style
A23010 Plug, 1/8" Pipe Hex Black All Manifolds
19
A29212 Pilot Tubing, ARCM ARSM New Style Double IR Burner
A29300 Valve, Pilot Elbow Adjustable 10418 1/8 NPT 3/16 CC
20
A99635 Crumb Tray, ARCM-24"
A99636 Crumb Tray, ARCM-36"
A99637 Crumb Tray, ARCM-48"
A99638 Crumb Tray, ARCM-60"
22
A14019 Burner, Infrared ARCM/ARSB New Style 16-9/16" x 8"
A14020 Burner, Infrared ARCM/ARSM New Style 27-5/8" x 8"
23
A99591 Bracket, Large IR Burner ARCM
A99592 Bracket, Small IR Burner ARCM
