AROB
ITEM NO. PART NO. DESCRIPTION
5 A14050 Burner, Infrared 19-3/4" x 8" AROB
7 A29232 Pilot, Tip Right Assembly Single AROB
8 A29300 Valve, Pilot Elbow Adjustable 10418 1/8NPT 2/16 CC
9 A32001 Knob, Gas On/Off Glossy Black Flat Down
10 A80109 Valve, Gas Manual On/Off UL 10419 AR, ARKB, ARRB, AECB
11
A29003 Orice Hood, #53 1/2" Brass Flat Head/MSD LP Gas AROB
A29012 Orice Hood, #43 1/2" Brass 11043 AROB
13 A29231 Pilot, Tip Left Assembly Single AROB
14
A31043 Skewer, (Shish Kabob) w/Handle Heavy Duty Stainless ARKB
A31044 Skewer, (Lule Kabob) w/Handle Heavy Duty Stainless ARKB
18 A38000 Name Plate, American Range 8" 10499 Quality Commercial Chrome
19 A44003 Nut, Speed #6 Push Black 10601
21
A80110 Valve, Pressure Regulator 3/4 10480 Nat Gas Set 5.
A80011 Valve, Pressure Regulator 3/4 10481 LP Gas Set 10.0
