Owner’s Manual
ARSM, ARSB, ARCM, AROB, AVB
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com
15
AVB
ITEM NO. PART NO. DESCRIPTION
1 A99627 Cover, Top AVCB-2 Heavy Duty 6000-A-01 Stainless Steel
2 A31028 Spit Guide, 6 Position AVB 10288
3
A99805 Bracket, Gas Pilot Rt IR Burner 70785R
A99806 Bracket, Gas Pilot Rt IR Burner 70785L
4 A99453 Plate, Spit Rotisserie Assembly 10289 AVB
5 A99656 Pan, Grease Funnel AVB 10603
6 A99452 Pan, Grease Collector AVB 10604
7
A80110 Valve, Pressure Regulator 3/4 10480 Nat Gas Set 5.
A80011 Valve, Pressure Regulator 3/4 10481 LP Gas Set 10.0
8
A38000 Name Plate, American Range 8" 10499 Quality Commercial Chrome
A44003 Nut, Speed #6 Push Black 10601
9 A10014 Switch, Toggle On/Off 115V 10417
10 A28028 Adapter, 3/8C x 3/8-27 Uns Brass
11 A29300 Valve, Pilot Elbow Adjustable 10418 1/8 NPT 3/16 CC
12 A80109 Valve, Gas Manual On/Off UL 10419 AR, ARKB, ARRB, AECB
13
A32001 Knob, Gas On/Off Glossy Black Flat Down
14 A32100 Handle, Assembly Front to Back 10605 Adjustment
15 A32008 Fan Blade, AVB Gear Motor
16 A91003 Motor, Gear 115V ACB-4, AVB 10410
17 A40005 Bearing, High Heat Flanged 3/4" 10429 Bore w/3 Set Screws
18 A13100 Cord, Power NEMA 5-15P SJT 16/3 6’ Black ROJ 5-1/2" Grn #10 Term
19 A29214 Pilot Tip, Assembly AVB 10239
20
A29105 Spud, Hex Orice #55 LP Gas Infrared
A29116 Spud, Hex Orice #47
A29400 Gas Supply, Assembly IR Burner AVB
21 A14016 Burner, Infrared AVB & AGBU 10620 Old Style 17-1/4" x 4"
22 A99807 Panel, Back AVB 18ga Aluminized Part 4
23 A99432 Panel, Side Heavy Duty Stainless 10290 AVB
